TM 90

Designed specifically for devotees of the cruising lifestyle, the new Custom Yacht TM90 optimizes the potential of an explorer yacht with Italian style but above all has an ease of use and a lot of handling and generates savings on crew expence and maintenance costs, the its management is as easy as that of a smaller yacht.

The low consumption, the comfort, and the great autonomy are its peculiarities and make the TM90 a Crossover Yacht characterized by modern shapes and look, ideal for sea cruiser long range and unexplored places, capable of carrying up to 18 people and hosting up to 12 people staying overnight , plus crew.

GallerY

Layout

Tm90 plan 1
Tm90 plan 2
Tm90 plan 5
Tm90 plan 3
Tm90 plan 4

Technical Data

The new Tm 90 custom line has been specifically designed to reduce maintenance costs. The space on board blends the interior with the exterior, increasing natural lighting. The design of the aft section and swimming platform allows ample stowage of jet skis, seabobs and tenders up to 4.5 meters. Available with three different engines: 800* hp of fast displacement with very low consumption; 1550 Man fast semi-displacement with speed range from 8 to 21 knots; 1900 hp a fast yacht with maximum speed 26 knots and 22 knots of cruising.

Dimensions :US UNITS
Length Over all (LOA)90” ft
Length waterline78’ 61” ft
Beam over all23’ 42” ft
Draft (with full load)5’ 90” ft
Displacement light load ab72.000kg
Displacement full load83.000 kg
Total fuel capacity9000 lt
Fresh water capacity1.200 lt
Grey water capacity450 lt
Black water capacity450 lt
Eco Speed12 Kn
Cruise Speed19 Kn
Maximum Speed22 Kn
People18
Beds8+4 crew


Recreational Craft Directive 94/25/CE of 16/06/1994 and subsequent amendments – RSG Guidelines, Design Category “A”
All the measures and diMensions can be have variations. Project: Terranova Italian Yachts

Hull

GRP in CE roules
Transverse and longitudinal reinforcement throughout hull.
The hull below waterline is covered with three layers of black antifouling paint.
Appropriate zinc plates installed for galvanic protection

Engines and propulsion

N° 2 Man 12V 1550HP
GB ZF
MAR17 shafts
5 blades propellers


You want to know all the customizations of TM 90?

Request the brochure or contact us to receive all the information you need.
